PCN2-S12-D12-S
Manufacturer:
Same Sky
Mfr.Part #:
PCN2-S12-D12-S
Datasheet:
Description:
DC to DC Converters SIP Through Hole Nominal Input Voltage:10.8 V to 13.2 V Min Input Voltage:10.8 V Max Input Voltage:13.2 V 82 %
| Parameter | Value |
|---|---|
| Length | 19.6 mm |
| Width | 7.2 mm |
| Max Operating Temperature | 100 °C |
| Min Operating Temperature | -40 °C |
| Height | 10.2 mm |
| Lead Free | Lead Free |
| RoHS | Compliant |
| Features | SCP |
| Min Input Voltage | 10.8 V |
| Max Power Dissipation | 2 W |
| Max Output Current | 83 mA |
| Max Input Voltage | 13.2 V |
| Number of Outputs | 2 |
| Isolation Voltage | 1 kV |
| Efficiency | 82 % |
| Voltage - Output 1 | 12 V |
| Voltage - Output 2 | -12 V |
| Schedule B | 8542390000 |
| Output Power | 2 W |
| Output Voltage-Channel 2 | -12 V |
| Output Current-Channel 1 | 83 mA |
| Output Current-Channel 2 | 83 mA |
| Output Voltage-Channel 1 | 12 V |
| Packaging | Tube |
| Nominal Input Voltage | 10.8 V to 13.2 V |
Stock: 19
Distributors
pcbx
pcbxUnit Price$4.92525
Ext.Price$4.92525
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $4.92525 | $4.92525 |
| 10 | $4.62431 | $46.24310 |
| 25 | $4.54670 | $113.66750 |
| 50 | $4.47039 | $223.51950 |
| 100 | $4.39536 | $439.53600 |
| 300 | $4.32159 | $1296.47700 |
| 500 | $4.24900 | $2124.50000 |
